| General information |
|---|
| Brand | Aston Martin |
|---|
| Model | DB9 |
|---|
| Generation | DB9 Coupe |
|---|
| Modification (Engine) | 6.0 i V12 48V (456 Hp) |
|---|
| Start of production | 2004 year |
|---|
| End of production | 2012 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Coupe |
|---|
| Seats | 4 |
|---|
| Doors | 2 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
24 l/100 km
9.8 US mpg11.77 UK mpg4.17 km/l |
| Fuel consumption (economy) - extra urban |
12 l/100 km
19.6 US mpg23.54 UK mpg8.33 km/l |
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 4.9 sec |
|---|
| Acceleration 0 - 62 mph | 4.9 sec |
|---|
| Acceleration 0 - 60 mph | 4.7 sec |
|---|
| Maximum speed |
300 km/h
186.41 mph |
| Weight-to-power ratio | 3.8 kg/Hp, 266.7 Hp/tonne |
|---|
| Weight-to-torque ratio | 3 kg/Nm, 333.3 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 456 Hp @ 6000 rpm. |
|---|
| Power per litre | 76.8 Hp/l |
|---|
| Torque |
570 Nm @ 5000 rpm.
420.41 lb.-ft. @ 5000 rpm. |
| Engine location | Front, Longitudinal |
|---|
| Engine displacement |
5935 cm3
362.18 cu. in. |
| Number of cylinders | 12 |
|---|
| Position of cylinders | V-engine |
|---|
| Cylinder Bore |
89 mm
3.5 in. |
| Piston Stroke |
79.5 mm
3.13 in. |
| Compression ratio | 10.3 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Multi-point indirect injection |
|---|
| Engine aspiration | Naturally aspirated engine |
|---|
| Valvetrain | DOHC |
|---|
| Engine oil capacity |
10.4 l
10.99 US qt | 9.15 UK qt |
| Oil viscosity | No Data |
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1710 kg
3769.9 lbs. |
| Trunk (boot) space - maximum |
175 l
6.18 cu. ft. |
| Fuel tank capacity |
85 l
22.45 US gal | 18.7 UK gal |
| Dimensions |
|---|
| Length |
4697 mm
184.92 in. |
| Width |
1875 mm
73.82 in. |
| Height |
1318 mm
51.89 in. |
| Wheelbase |
2740 mm
107.87 in. |
| Front track |
1568 mm
61.73 in. |
| Rear (Back) track |
1562 mm
61.5 in. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
|---|
| Drive wheel | Rear wheel drive |
|---|
| Number of Gears (manual transmission) | 6 |
|---|
| Front suspension | Double wishbone |
|---|
| Rear suspension | Double wishbone |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Ventilated discs |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Hydraulic Steering |
|---|
| Tires size | Front wheel tires: 235/40 ZR19Rear wheel tires: 275/35 ZR19 |
| Wheel rims size | Front wheel rims: 8.5J x 19Rear wheel rims: 9.5J x 19 |
|---|
|
|---|
