| General information |
|---|
| Brand | Jeep |
|---|
| Model | Wrangler |
|---|
| Generation | Wrangler III (JK) |
|---|
| Modification (Engine) | 2.8 CRDi Sport (174 Hp) 4x4 |
|---|
| Start of production | 2007 year |
|---|
| End of production | 2009 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Off-road vehicle |
|---|
| Seats | 4 |
|---|
| Doors | 3 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
12.7 l/100 km
18.52 US mpg22.24 UK mpg7.87 km/l |
| Fuel consumption (economy) - extra urban |
8.3 l/100 km
28.34 US mpg34.03 UK mpg12.05 km/l |
| Fuel consumption (economy) - combined |
9.9 l/100 km
23.76 US mpg28.53 UK mpg10.1 km/l |
| CO2 emissions | 263 g/km |
|---|
| Fuel Type | Diesel |
|---|
| Acceleration 0 - 100 km/h | 11.2 sec |
|---|
| Acceleration 0 - 62 mph | 11.2 sec |
|---|
| Acceleration 0 - 60 mph | 10.6 sec |
|---|
| Maximum speed |
180 km/h
111.85 mph |
| Emission standard | Euro 4 |
|---|
| Weight-to-power ratio | 10.4 kg/Hp, 96.4 Hp/tonne |
|---|
| Weight-to-torque ratio | 4.4 kg/Nm, 227.1 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 174 Hp @ 3800 rpm. |
|---|
| Power per litre | 62.7 Hp/l |
|---|
| Torque |
410 Nm @ 2000-3200 rpm.
302.4 lb.-ft. @ 2000-3200 rpm. |
| Maximum engine speed | 4500 rpm. |
|---|
| Engine location | Front, Longitudinal |
|---|
| Engine displacement |
2776 cm3
169.4 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
94 mm
3.7 in. |
| Piston Stroke |
100 mm
3.94 in. |
| Compression ratio | 17.5 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Diesel Commonrail |
|---|
| Engine aspiration | Turbocharger |
|---|
| Valvetrain | DOHC |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1805 kg
3979.34 lbs. |
| Max. weight |
2501 kg
5513.76 lbs. |
| Max load |
696 kg
1534.42 lbs. |
| Trunk (boot) space - minimum |
142 l
5.01 cu. ft. |
| Trunk (boot) space - maximum |
430 l
15.19 cu. ft. |
| Fuel tank capacity |
66 l
17.44 US gal | 14.52 UK gal |
| Dimensions |
|---|
| Length |
4223 mm
166.26 in. |
| Width |
1873 mm
73.74 in. |
| Height |
1816 mm
71.5 in. |
| Wheelbase |
2424 mm
95.43 in. |
| Front track |
1572 mm
61.89 in. |
| Rear (Back) track |
1572 mm
61.89 in. |
| Ride height (ground clearance) |
238 mm
9.37 in. |
| Drag coefficient (Cd) | 0.495 |
|---|
| Minimum turning circle (turning diameter) |
10.36 m
33.99 ft. |
| Approach angle | 36.4° |
|---|
| Departure angle | 29.8° |
|---|
| Ramp-over (brakeover) angle | 23.1° |
|---|
| Drivetrain, brakes and suspension specs |
|---|
| Drive wheel | All wheel drive (4x4) |
|---|
| Number of Gears (manual transmission) | 6 |
|---|
| Front suspension | Multi-link suspension |
|---|
| Rear suspension | Multi-link independent |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Tires size | 225/75 R16 |
| Wheel rims size | 16 |
|---|
|
|---|
