| General information |
|---|
| Brand | Mercedes-Benz |
|---|
| Model | S-class |
|---|
| Generation | Maybach S-class (Z223) |
|---|
| Modification (Engine) | S 580 V8 EQ Boost (503 Hp) 4MATIC 9G-TRONIC |
|---|
| Start of production | 2021 year |
|---|
| Powertrain Architecture | MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV) |
|---|
| Body type | Sedan |
|---|
| Seats | 4 |
|---|
| Doors | 4 |
|---|
| Performance specs |
|---|
| Combined fuel consumption (WLTP) |
10.4-11.7 l/100 km
22.62 - 20.1 US mpg27.16 - 24.14 UK mpg9.62 - 8.55 km/l |
| CO2 emissions (WLTP) | 236-267 g/km |
|---|
| Fuel consumption (economy) - urban (NEDC) |
15.2-15.7 l/100 km
15.47 - 14.98 US mpg18.58 - 17.99 UK mpg6.58 - 6.37 km/l |
| Fuel consumption (economy) - extra urban (NEDC) |
7.3-8.1 l/100 km
32.22 - 29.04 US mpg38.7 - 34.87 UK mpg13.7 - 12.35 km/l |
| Fuel consumption (economy) - combined (NEDC) |
10.2-10.9 l/100 km
23.06 - 21.58 US mpg27.69 - 25.92 UK mpg9.8 - 9.17 km/l |
| CO2 emissions (NEDC) | 233-248 g/km |
|---|
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 4.8 sec |
|---|
| Acceleration 0 - 62 mph | 4.8 sec |
|---|
| Acceleration 0 - 60 mph | 4.6 sec |
|---|
| Maximum speed |
250 km/h, Electronically limited
155.34 mph |
| Emission standard | Euro 6D-ISC-FCM |
|---|
| Weight-to-power ratio | 4.4 kg/Hp, 227.1 Hp/tonne |
|---|
| Weight-to-torque ratio | 3.2 kg/Nm, 316 Nm/tonne |
|---|
| Electric cars and hybrids specs |
|---|
| Electric motor 1 |
|---|
| Electric motor power | 20 Hp |
|---|
| Electric motor Torque |
200 Nm
147.51 lb.-ft. |
| Engine location | Electric motor, integrated into transmission |
|---|
| Internal combustion engine specs |
|---|
| Power | 503 Hp @ 5500 rpm. |
|---|
| Power per litre | 126.3 Hp/l |
|---|
| Torque |
700 Nm @ 2000-4500 rpm.
516.29 lb.-ft. @ 2000-4500 rpm. |
| Engine location | Front, Longitudinal |
|---|
| Engine Model/Code | M 176 |
|---|
| Engine displacement |
3982 cm3
243 cu. in. |
| Number of cylinders | 8 |
|---|
| Position of cylinders | V-engine |
|---|
| Cylinder Bore |
83 mm
3.27 in. |
| Piston Stroke |
92 mm
3.62 in. |
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Direct injection |
|---|
| Engine aspiration | BiTurbo, Intercooler |
|---|
| Valvetrain | DOHC |
|---|
| Engine oil capacity |
9.5 l
10.04 US qt | 8.36 UK qt |
| Engine systems | Start & Stop SystemCylinder deactivation systemParticulate filter |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
2215 kg
4883.24 lbs. |
| Max. weight |
2910 kg
6415.45 lbs. |
| Max load |
695 kg
1532.21 lbs. |
| Trunk (boot) space - minimum |
505 l
17.83 cu. ft. |
| Fuel tank capacity |
76 l
20.08 US gal | 16.72 UK gal |
| Dimensions |
|---|
| Length |
5469 mm
215.31 in. |
| Width |
1921 mm
75.63 in. |
| Width including mirrors |
2109 mm
83.03 in. |
| Height |
1510 mm
59.45 in. |
| Wheelbase |
3396 mm
133.7 in. |
| Front track |
1655 mm
65.16 in. |
| Rear (Back) track |
1683 mm
66.26 in. |
| Front overhang |
877 mm
34.53 in. |
| Rear overhang |
1196 mm
47.09 in. |
| Ride height (ground clearance) |
130 mm
5.12 in. |
| Approach angle | 14.7° |
|---|
| Departure angle | 15.4° |
|---|
| Ramp-over (brakeover) angle | 9.9° |
|---|
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) and the electric motor permanently drive the four wheels of the car with the ability to work only in mixed mode. |
|---|
| Drive wheel | All wheel drive (4x4) |
|---|
| Number of Gears (automatic transmission) | 9G-TRONIC |
|---|
| Front suspension | Pneumatic suspension |
|---|
| Rear suspension | Pneumatic suspension |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Ventilated discs |
|---|
| Assisting systems | ABS (Anti-lock braking system)4-wheel steering (4WS, active rear steering) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Electric Steering |
|---|
| Tires size | Front wheel tires: 255/45 R19; 255/40 R20; 265/35 R21Rear wheel tires: 255/45 R19; 255/40 R20; 285/35 R20; 265/35 R21 |
| Wheel rims size | Front wheel rims: 8.5J x 19; 9J x 20; 9J x 21Rear wheel rims: 8.5J x 19; 9J x 20; 10J x 20; 9J x 21 |
|---|
|
|---|
