| General information |
|---|
| Brand | Renault |
|---|
| Model | Scenic |
|---|
| Generation | Grand Scenic IV (Phase I) |
|---|
| Modification (Engine) | 1.2 Energy TCe (115 Hp) |
|---|
| Start of production | 2016 year |
|---|
| End of production | 2018 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Minivan |
|---|
| Seats | 5 |
|---|
| Doors | 5 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
7.5 l/100 km
31.36 US mpg37.66 UK mpg13.33 km/l |
| Fuel consumption (economy) - extra urban |
5.3 l/100 km
44.38 US mpg53.3 UK mpg18.87 km/l |
| Fuel consumption (economy) - combined |
6.1 l/100 km
38.56 US mpg46.31 UK mpg16.39 km/l |
| CO2 emissions | 136 g/km |
|---|
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 12.5 sec |
|---|
| Acceleration 0 - 62 mph | 12.5 sec |
|---|
| Acceleration 0 - 60 mph | 11.9 sec |
|---|
| Maximum speed |
195 km/h
121.17 mph |
| Emission standard | Euro 6 b |
|---|
| Weight-to-power ratio | 12.4 kg/Hp, 80.4 Hp/tonne |
|---|
| Weight-to-torque ratio | 7.5 kg/Nm, 132.9 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 115 Hp @ 4500 rpm. |
|---|
| Power per litre | 96 Hp/l |
|---|
| Torque |
190 Nm @ 2000 rpm.
140.14 lb.-ft. @ 2000 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine Model/Code | H5F |
|---|
| Engine displacement |
1198 cm3
73.11 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
72.2 mm
2.84 in. |
| Piston Stroke |
73.2 mm
2.88 in. |
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Direct injection |
|---|
| Engine aspiration | Turbocharger |
|---|
| Engine oil capacity |
4.6 l
4.86 US qt | 4.05 UK qt |
| Oil viscosity | No Data |
| Coolant |
6.5 l
6.87 US qt | 5.72 UK qt |
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1430 kg
3152.61 lbs. |
| Max. weight |
2160 kg
4761.98 lbs. |
| Max load |
730 kg
1609.37 lbs. |
| Trunk (boot) space - minimum |
718 l
25.36 cu. ft. |
| Trunk (boot) space - maximum |
1901 l
67.13 cu. ft. |
| Fuel tank capacity |
53 l
14 US gal | 11.66 UK gal |
| Max. roof load |
80 kg
176.37 lbs. |
| Permitted trailer load with brakes (12%) |
1850 kg
4078.55 lbs. |
| Permitted trailer load without brakes |
750 kg
1653.47 lbs. |
| Permitted towbar download |
75 kg
165.35 lbs. |
| Dimensions |
|---|
| Length |
4635 mm
182.48 in. |
| Width |
1866 mm
73.46 in. |
| Width including mirrors |
2128 mm
83.78 in. |
| Height |
1660 mm
65.35 in. |
| Wheelbase |
2804 mm
110.39 in. |
| Front track |
1602 mm
63.07 in. |
| Rear (Back) track |
1596 mm
62.83 in. |
| Front overhang |
931 mm
36.65 in. |
| Rear overhang |
899 mm
35.39 in. |
| Ride height (ground clearance) |
159 mm
6.26 in. |
| Minimum turning circle (turning diameter) |
11.39 m
37.37 ft. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 6 |
|---|
| Front suspension | Independent type McPherson |
|---|
| Rear suspension | Semi-independent, coil spring |
|---|
| Front brakes | Ventilated discs, 320 mm |
|---|
| Rear brakes | Disc, 290 mm |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Electric Steering |
|---|
| Tires size | 195/55 R20 95H |
| Wheel rims size | 20 |
|---|
|
|---|
